Name: Recoil Pull Start - RED Metal - 2.8hp Motovox MBX10, MBX11 97cc Pit Bike
Brand: VMC Chinese Parts
Price: 14.95 USD
Availability: InStock

Same Day Shipping On Orders Before 3PM, M-F

0 items - $ 0.00 / Sign in or Checkout

Recoil Pull Start - RED Metal - 2.8hp Motovox MBX10, MBX11 97cc Pit Bike - VMC Chinese Parts

VMC Chinese Parts

Part number: 936-PR436-05 RED

Pull Start Assembly Chinese 2.8hp 97cc Motovox MBX10 and MBX11

This Chinese pull start is used on several makes and models of atvs and pocket bikes, and may also work on generators, mowers, etc. Please use the measurements and picture to best match the pull start you are needing.

Pull start details:

Metal - RED
Overall OD: Approx. 150mm
Rope spool OD: Approx. 109mm
Metal spring cover OD: 54mm
Plastic catch ID: 80mm
Mounting hole distance: 67mm (2.6 in) beside center-to-center
Mounting hole distance: 134mm (5.28 in) across center-to-center

Known to fit Baja Doodlebug, Motovox MBX10 and MBX11 and Chinese clones.

Shopping for Chinese ATV Parts or Chinese Scooter Parts is a bit different than shopping for parts for a domestic or Japanese machine, for a couple of reasons. First, most Chinese machines are assembled with aftermarket parts; there are no OEM parts. Because Chinese machines are assembled with parts from a variety of manufacturers for the same application, even in the same model and model year, cross-referencing numbers stamped on the original part is usually not possible. Secondly, there is a bit of an "as is" attitude towards Chinese-built machines; there simply aren't model specific parts catalogs available. For those reasons, shopping for parts for a Chinese-built machine is largely a visual exercise: rather than ordering parts by make, model and production date, the best way to ensure that the part ordered is correct is to match the specifications of the parts.

At VMC Chinese Parts, our objective is to get you the right part, the first time, with thorough measurements and multiple images. In the event, however, that there is still uncertainty about a part's application, we encourage you to contact us, and be prepared to provide pictures and dimensions of the part in question. Visual verification is the best means to get you the correct part, and get your Chinese-built machine back on the trail or road!
